- 5 10/100/1000Mbps auto-negotiated RJ45 ports.
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode.
- 2K entry MAC address table and automatic address learning.
- Auto-MDI/MDIX eliminates the need for crossover cables.
- Store- and-Forward Switching scheme.
- Performs non-blocking full wired speed.
- Supports Giga Lite to improve transfer rate for 4-wire UTP gigabit network.
General | |
|---|---|
| Standards |
- IEEE 802.3, - IEEE 802.3u, - IEEE 802.3ab, - IEEE 802.3x |
| Interface | - 5*10/100/1000Mbps auto-negotiation RJ-45 Ports (Auto MDI/MDIX) |
| Power Supply | - 9V DC/0.5A |
Dimensions(L x W x H) |
- 5.2 x 3.0 x 1.0 in. (132 x 75 x 25mm)(L x W x H) |
| LED | - 1*Power, 5*LANs |
MAC Address Learning |
- Auto-learning, Auto-Aging |
MAC Address Table |
- 2K |
Network Media |
- 10BASE-T: UTP Cat 3, 4, 5 cable - 100BASE-TX/1000BASE-T: UTP Cat 5, 5e or above cable |
Backup Bandwidth |
- 10 Gbps |
Transmission Method |
- Store-and-Forward |
Others | |
Package Contents |
- S505G Desktop Switch *1 - Power Adapter - Quick Installation Guide *1 |
Environment |
- Operating Temperature: 0℃~50℃ (32℉~122℉) - Storage Temperature: -40~70℃ (-40℉~158℉) - Operating Humidity: 5%~95% non-condensing - Storage Humidity: 5%~95% non-condensing |
